Даташит apl1084 pdf ( datasheet )

Application Notes

• A Topical Index of TI LDO Application Notes (Rev. F)

  PDF, 82 Кб, Версия: F, Файл опубликован: 27 июн 2019

• Digital Designer’s Guide to Linear Voltage Regulators & Thermal Mgmt (LDO) (Rev. A)

  PDF, 509 Кб, Версия: A, Файл опубликован: 4 июн 2008

• Method For Cal Output Voltage Tolerances in Adj Regs (Rev. A)

  PDF, 284 Кб, Версия: A, Файл опубликован: 5 май 2013When working with voltage regulator circuits the designer is often confronted with the need to calculatethe tolerance of the regulated output voltage. For fixed voltage regulators this problem is easily managedbecause the required information is directly supplied on the semiconductor manufacturer’s data sheet.

• AN-1148 Linear Regulators: Theory of Operation and Compensation (Rev. B)

  PDF, 300 Кб, Версия: B, Файл опубликован: 6 май 2013This application note discusses the operation and compensation of linear regulators.

• AN-103 LM340 Series Three Terminal Positive Regulators (Rev. A)

  PDF, 814 Кб, Версия: A, Файл опубликован: 6 май 2013The LM340-XX are three terminal 1.0A positive voltage regulators with preset output voltages of 5.0V or15V. The LM340 regulators are complete 3-terminal regulators requiring no external components fornormal operation. However by adding a few parts one may improve the transient response provide for avariable output voltage or increase the output current. Included on the chip are all of t

• Understanding the Terms and Definitions of LDO Voltage Regulators

  PDF, 197 Кб, Файл опубликован: 21 окт 1999This report provides an understanding of the terms and definitions of low dropout (LDO) voltage regulators and describes fundamental concepts including dropout voltage quiescent current standby current efficiency transient response line/load regulation power supply rejection output noise voltage accuracy and power dissipation. Each section includes an example to increase the understandab

• Packaging Limits Range of Linear Regulators

  PDF, 75 Кб, Файл опубликован: 8 май 2010The power limitations of the physical packaging for a linear regulator device can limit the total output current or the input-to-output voltage differential. This inherent limitation is not always apparent from the product data sheet and must be evaluated during the design phase. This application note shows how the package can limit the operating envelope of a linear regulator.

Related Datasheets

Datasheets

ProductFolder Sample &Buy Support &Community Tools &Software TechnicalDocuments LM1084SNVS037G – SEPTEMBER 1999 – REVISED JANUARY 2015 LM1084 5-A Low Dropout Positive Regulators1 Features 3 Description The LM1084 is a regulator with a maximum dropoutof 1.5 V at 5 A of load current. The device has thesame pinout as TI’s industry standard LM317. 1 Available in 3.3-V, 5.0-V, and Adjustable VersionsCurrent Limiting and Thermal ProtectionOutput Current 5 AIndustrial Temperature Range -40В°C to 125В°CLine Regulation 0.015% (Typical)Load Regulation 0.1% (Typical) 2 Applications Post Regulator for Switching DC-DC ConverterHigh-Efficiency Linear RegulatorsBattery Chargers Two resistors are required to set the output voltage ofthe adjustable output voltage version of the LM1084.Fixed output voltage versions integrate the adjustresistors.The LM1084 circuit includes a zener trimmedbandgap reference, current limiting, and thermalshutdown. …

Datasheets

ProductFolder Sample &Buy Support &Community Tools &Software TechnicalDocuments LM1084SNVS037G – SEPTEMBER 1999 – REVISED JANUARY 2015 LM1084 5-A Low Dropout Positive Regulators1 Features 3 Description The LM1084 is a regulator with a maximum dropoutof 1.5 V at 5 A of load current. The device has thesame pinout as TI’s industry standard LM317. 1 Available in 3.3-V, 5.0-V, and Adjustable VersionsCurrent Limiting and Thermal ProtectionOutput Current 5 AIndustrial Temperature Range -40В°C to 125В°CLine Regulation 0.015% (Typical)Load Regulation 0.1% (Typical) 2 Applications Post Regulator for Switching DC-DC ConverterHigh-Efficiency Linear RegulatorsBattery Chargers Two resistors are required to set the output voltage ofthe adjustable output voltage version of the LM1084.Fixed output voltage versions integrate the adjustresistors.The LM1084 circuit includes a zener trimmedbandgap reference, current limiting, and thermalshutdown. …
