LM2576T-ADJ Datasheet Download — ETC

Номер произв

LM2576T-ADJ

Описание

3A Step-Down Voltage Regulator

Производители

ETC

логотип

1Page

No Preview Available !

LM2576
3A Step-Down Voltage Regulator
GENERAL DESCRIPTION
The LM2576 Series are step-down switching
regulators with all required active functions. It is
capable of driving 3A load with excellent line and
load regulations. These devices are available in
fixed output voltages of 3.3V, 5V, 12V and an
adjustable output version.
The LM2576 series offers a high-efficiency
replacement for popular three-terminal linear
regulators. Also it requires a minimum number of
external components. It substantially not only
reduces the area of board size but also the size of
heat sink, and in some cases no heat sink is
required. The ±4% tolerance on output voltage
within specified input voltages and output load
conditions is guaranteed. Also, the oscillator
frequency accuracy is within ±10%. External
shutdown is included. Featuring 80µA (typical)
standby current. The output switch includes
cycle-by-cycle current limiting, as well as thermal
shutdown for full protection under fault conditions.
This series are offered in 5-pin TO-263,
TO-220 package.
Block Diagram
FEATURES

Guaranteed 3A output current.

3.3V, 5V, 12Vand adjustable versions,

Wide input voltage range, up to 45V

Internal oscillator of 52KHz fixed frequency.

Wide adjust version output voltage range,

from 1.23V to 37V ±4% max. at over line and
load conditions.

Low standby current, typ. 80µA, at shutdown

mode

Requires only 4 external components

Thermal shutdown and current limit

protection

P+ product enhancement tested

APPLICATIONS

LCD Monitors.

ADD-ON Cards Switching Regulators

High Efficiency Step-Down Regulators

Efficient Pre-regulator for Linear Regulators

Positive to Negative converter (Buck-Boost)

DC Input
+
Vin
1
Internal
Regulator
Enable
Enable
5
4
Feed
Back
R2

R1
1K
1.23V
Band-Gap
Reference
Fixed Gain
3Amp.

Error amp. Comparator Driver Switch

Thermal
Shutdown
52KHz
Oscillator
Reset
Current
Limited
Output
2
3
L1
+
Cout
D1
Ver1.0
1

No Preview Available !

Ordering Information
LM2576
Part No.
LM2576T-XX
LM2576T-ADJ
LM2576S-ADJ
LM2576S-XX
Operating Temp.
(Ambient)

-20 ~ +85℃

Package
TO-220-5L
TO-263-5L

Note: Where XX denotes voltage option, Available are 12V, 5V and 3.3V. Leave blank for

adjustable version. Contact factory for additional voltage options.
Pin assignment
TO-220
TO-263
1. Input
2. Output
3. Ground
4. Feedback
5. Enable
Absolute Maximum Ratings
Input voltage
Vin
ENABLE Pin Input Voltage
Vin (operate)
Power Dissipation

Operating Junction Temperature Range

Storage Temperature Range

TSTG

+45

-0.3V ≤ V ≤ Vin

Internal Limited
-40 ~ +150
-65 ~ +150

Lead Soldering Temperature (260℃)

TO-220-5L / TO-263-5L
Package
10
V
V
W
℃
℃
S
Ver1.0
2

No Preview Available !

Electrical Characteristics

Vin = 12V, IL= 500mA, Ta = 25oC unless otherwise specified.

Parameter
Conditions
LM2576-3.3V

Output Voltage (Note 1) Vin=12V, IL=0.5A (Figure 1)

0.5A ≤IL ≤3A, 6V ≤Vin ≤45V

Output Voltage (Note 1)
(Figure 1)
Efficiency

Vin=12V, IL=3A

LM2576-5V

Output Voltage (Note 1) Vin=12V, IL=0.5A(Figure 1)

0.5A ≤IL ≤3A, 8V ≤Vin ≤45V

Output Voltage (Note 1)
(Figure 1)
Efficiency

Vin=12V, IL=3A

LM2576-12V

Output Voltage (Note 1) Vin=25V, IL=0.5A (Figure 1)

0.5A ≤IL ≤3A, 15V ≤Vin ≤45V

Output Voltage(Note 1)
(Figure 1)
Efficiency

Vin=15V, IL=3A

LM2576
Feedback Voltage
(Note 1)
Feedback Voltage
(Note 1)
Efficiency

Vin=12V, Vout=5V,IL=0.5A

(Figure 2)

0.5A ≤IL ≤3A, 8V ≤Vin ≤45V,

Vout=5V (Figure 2)

Vin=12V, Vout=5V, IL=3A

Min
0.98|Vo|
0.96|Vo|
—
0.98|Vo|
0.96|Vo|
—
0.98|Vo|
0.96|Vo|
—
0.98|Vo|
0.96|Vo|
—
Typ
3.3
75
5.0
77
12
88
1.23
77
LM2576
Max Unit
1.02|Vo|
1.04|Vo|
V
— %
1.02|Vo|
1.04|Vo|
V
— %
1.02|Vo|
1.04|Vo|
V
— %
1.02|Vo|
1.04|Vo|
V
— %
Ver1.0
3

Всего страниц

8 Pages

Скачать PDF

Application Notes

Datasheet texas instruments lm2940ct-15
High-Efficiency 3A Battery Chargers Use LM2576 Regulators (Rev. B)

PDF, 187 Кб, Версия: B, Файл опубликован: 23 апр 2013This application report describes two LM2576-based designs that provide up to 3A of current for batterycharging.
Battery Charging

PDF, 146 Кб, Файл опубликован: 21 мар 2007
AN-776 20-W SIMPLE SWITCHER Forward Converter (Rev. A)

PDF, 593 Кб, Версия: A, Файл опубликован: 23 апр 2013This application note provides information about the 20-watt simple switcher forward converter.
AN-1246 Stresses in Wide Input DC-DC Converters (Rev. C)

PDF, 427 Кб, Версия: C, Файл опубликован: 23 апр 2013This application note discusses stresses in wide input DC-DC converters.
Buck Converters Provide a Battery Charger and System Power

PDF, 61 Кб, Файл опубликован: 21 мар 2007
AN-1197 Selecting Inductors for Buck Converters (Rev. B)

PDF, 558 Кб, Версия: B, Файл опубликован: 23 апр 2013This application report provides design information to help select an off-the-shelf inductor for anycontinuous-mode buck converter application.
Semiconductor and IC Package Thermal Metrics (Rev. C)

PDF, 201 Кб, Версия: C, Файл опубликован: 19 апр 2016
Switching Regulator Fundamentals (Rev. A)

PDF, 324 Кб, Версия: A, Файл опубликован: 23 сен 2016Theswitchingregulatoris increasingin popularitybecauseit offersthe advantagesof higherpowerconversionefficiencyand increaseddesignflexibility(multipleoutputvoltagesof differentpolaritiescan begeneratedfroma singleinputvoltage).
Input and Output Capacitor Selection

PDF, 219 Кб, Файл опубликован: 19 сен 2005
AN-643 EMI/RFI Board Design (Rev. B)

PDF, 742 Кб, Версия: B, Файл опубликован: 3 май 2004Application Note 643 EMI/RFI Board Design
AN-1149 Layout Guidelines for Switching Power Supplies (Rev. C)

PDF, 82 Кб, Версия: C, Файл опубликован: 23 апр 2013When designing a high frequency switching regulated power supply layout is very important. Using agood layout can solve many problems associated with these types of supplies. The problems due to a badlayout are often seen at high current levels and are usually more obvious at large input to output voltagedifferentials. Some of the main problems are loss of regulation at high output current
AN-1229 SIMPLE SWITCHER PCB Layout Guidelines (Rev. C)

PDF, 374 Кб, Версия: C, Файл опубликован: 23 апр 2013This application report provides SIMPLE SWITCHER PCB layout guidelines.
Low EMI Layout Made SIMPLE With LM43600/1/2/3 and LM46000/1/2 (Rev. A)

PDF, 512 Кб, Версия: A, Файл опубликован: 12 сен 2014Printed Circuit Board (PCB) layout for Switched Mode Power Supplies (SMPS) is critical to achieve proper converter operation good thermal performance and excellent radiated EMI performance. Optimized board layout for low radiated EMI is made very simple by the package and pin arrangement of the SIMPLE SWITCHER Synchronous Buck Converter family LM4360x and LM4600x

Цены

Datasheet texas instruments lp2951

30 предложений от 18 поставщиков
Исполнение: TO-263-5. DC/DC CONVERTER; Voltage Regulator Type:Step Down (Buck); Voltage, Input Max:40V; Voltage, Output Max:37V; Current, Output Max:3A; Accuracy, Percentage:4%; Voltage,…

ЭлрусРоссия	LM2576S-ADJ/NOPBTexas Instruments	от 47 ₽	Купить
ТриемаРоссия	LM2576S-ADJ/NOPB, TO263Texas Instruments	63 ₽	Купить
Электродеталь- ПоставкаРоссия	LM2576S-ADJ/NOPB TO263-5 DC/DC преобразователь напряжения (Step-Down), 1.23-37V/3A, Fosc=52kHz МикросхемыTexas Instruments	по запросу	Купить
LifeElectronicsРоссия	LM2576SADJNOPBSemtech	по запросу	Купить

Статус

	LM2576S-12	LM2576S-12/NOPB	LM2576S-3.3/NOPB	LM2576S-5.0	LM2576S-5.0/NOPB	LM2576S-ADJ/NOPB	LM2576SX-3.3/NOPB	LM2576SX-5.0/NOPB	LM2576SX-ADJ/NOPB	LM2576T-12	LM2576T-12/LB03	LM2576T-12/LF03	LM2576T-12/NOPB	LM2576T-15/LF03	LM2576T-15/NOPB	LM2576T-3.3/LB03	LM2576T-3.3/LF03	LM2576T-3.3/NOPB	LM2576T-5.0	LM2576T-5.0/LB03	LM2576T-5.0/LF02	LM2576T-5.0/LF03	LM2576T-5.0/NOPB	LM2576T-ADJ	LM2576T-ADJ/LB03	LM2576T-ADJ/LF02	LM2576T-ADJ/LF03	LM2576T-ADJ/NOPB
Статус продукта	Не рекомендуется для новых разработок	В производстве	В производстве	Не рекомендуется для новых разработок	В производстве	В производстве	В производстве	В производстве	В производстве	Не рекомендуется для новых разработок	Не рекомендуется для новых разработок	В производстве	В производстве	В производстве	В производстве	Не рекомендуется для новых разработок	В производстве	В производстве	Не рекомендуется для новых разработок	Не рекомендуется для новых разработок	В производстве	В производстве	В производстве	Не рекомендуется для новых разработок	Не рекомендуется для новых разработок	В производстве	В производстве	В производстве
Доступность образцов у производителя	Да	Нет	Да	Нет	Да	Нет	Нет	Нет	Нет	Нет	Да	Нет	Нет	Да	Да	Да	Да	Да	Нет	Нет	Да	Нет	Нет	Нет	Нет	Нет	Да	Да

Datasheet texas instruments sn74hc164n

Datasheets

ProductFolder Sample &Buy TechnicalDocuments Support &Community Tools &Software LM2576, LM2576HVSNVS107D вЂ“ JUNE 1999 вЂ“ REVISED MAY 2016 LM2576xx Series SIMPLE SWITCHERВ 3-A Step-Down Voltage Regulator1 Features 3 Description The LM2576 series of regulators are monolithicintegrated circuits that provide all the active functionsfor a step-down (buck) switching regulator, capable ofdriving 3-A load with excellent line and loadregulation. These devices are available in fixed outputvoltages of 3.3 V, 5 V, 12 V, 15 V, and an adjustableoutput version. 1 3.3-V, 5-V, 12-V, 15-V, and Adjustable OutputVersionsAdjustable Version Output Voltage Range,1.23 Vto 37 V (57 V for HV Version) В±4% Maximum OverLine and Load ConditionsSpecified 3-A Output CurrentWide Input Voltage Range: 40 V Up to 60 V forHV VersionRequires Only 4 External Components52-kHz Fixed-Frequency Internal Oscillator …

Datasheets

Параметры

Parameters / Models	LM2576S-12	LM2576S-12/NOPB	LM2576S-3.3/NOPB	LM2576S-5.0	LM2576S-5.0/NOPB	LM2576S-ADJ/NOPB	LM2576SX-3.3/NOPB	LM2576SX-5.0/NOPB	LM2576SX-ADJ/NOPB	LM2576T-12	LM2576T-12/LB03	LM2576T-12/LF03	LM2576T-12/NOPB	LM2576T-15/LF03	LM2576T-15/NOPB	LM2576T-3.3/LB03	LM2576T-3.3/LF03	LM2576T-3.3/NOPB	LM2576T-5.0	LM2576T-5.0/LB03	LM2576T-5.0/LF02	LM2576T-5.0/LF03	LM2576T-5.0/NOPB	LM2576T-ADJ	LM2576T-ADJ/LB03	LM2576T-ADJ/LF02	LM2576T-ADJ/LF03	LM2576T-ADJ/NOPB
Approx. Price (US$)																1.19 \| 1ku
Control Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode	Voltage Mode
Duty Cycle(Max), %	98	98	98	98	98	98	98	98	98	98	98	98	98	98	98		98	98	98	98	98	98	98	98	98	98	98	98
Duty Cycle(Max)(%)																98
Основные особенности	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable		Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable	Enable
Iout(Max), A	3	3	3	3	3	3	3	3	3	3	3	3	3	3	3		3	3	3	3	3	3	3	3	3	3	3	3
Iout(Max)(A)																3
Iq(Typ), мА	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5		5	5	5	5	5	5	5	5	5	5	5	5
Iq(Typ)(mA)																5
Рабочий диапазон температур, C	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125		от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125	от -40 до 125
Operating Temperature Range(C)																-40 to 125
Package Group	DDPAK/TO-263	DDPAK/TO-263	DDPAK/TO-263	DDPAK/TO-263	DDPAK/TO-263	DDPAK/TO-263	DDPAK/TO-263	DDPAK/TO-263	DDPAK/TO-263	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220
Rating	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog	Catalog
Regulated Outputs	1	1	1	1	1	1	1	1	1	1	1	1	1	1	1		1	1	1	1	1	1	1	1	1	1	1	1
Regulated Outputs(#)																1
Special Features																Enable
Switching Frequency(Max), kHz	63	63	63	63	63	63	63	63	63	63	63	63	63	63	63		63	63	63	63	63	63	63	63	63	63	63	63
Switching Frequency(Max)(kHz)																63
Switching Frequency(Min), kHz	42	42	42	42	42	42	42	42	42	42	42	42	42	42	42		42	42	42	42	42	42	42	42	42	42	42	42
Switching Frequency(Min)(kHz)																42
Тип	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter	Converter
Vin(Max), В	40	40	40	40	40	40	40	40	40	40	40	40	40	40	40		40	40	40	40	40	40	40	40	40	40	40	40
Vin(Max)(V)																40
Vin(Min), В	4	4	4	4	4	4	4	4	4	4	4	4	4	4	4		4	4	4	4	4	4	4	4	4	4	4	4
Vin(Min)(V)																4
Vout(Max), В	37	37	37	37	37	37	37	37	37	37	37	37	37	37	37		37	37	37	37	37	37	37	37	37	37	37	37
Vout(Max)(V)																37
Vout(Min), В	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3		3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3	3.3
Vout(Min)(V)																3.3

Экологический статус

	LM2576S-12	LM2576S-12/NOPB	LM2576S-3.3/NOPB	LM2576S-5.0	LM2576S-5.0/NOPB	LM2576S-ADJ/NOPB	LM2576SX-3.3/NOPB	LM2576SX-5.0/NOPB	LM2576SX-ADJ/NOPB	LM2576T-12	LM2576T-12/LB03	LM2576T-12/LF03	LM2576T-12/NOPB	LM2576T-15/LF03	LM2576T-15/NOPB	LM2576T-3.3/LB03	LM2576T-3.3/LF03	LM2576T-3.3/NOPB	LM2576T-5.0	LM2576T-5.0/LB03	LM2576T-5.0/LF02	LM2576T-5.0/LF03	LM2576T-5.0/NOPB	LM2576T-ADJ	LM2576T-ADJ/LB03	LM2576T-ADJ/LF02	LM2576T-ADJ/LF03	LM2576T-ADJ/NOPB
RoHS	See ti.com	Совместим	Совместим	See ti.com	Совместим	Совместим	Совместим	Совместим	Совместим	See ti.com	See ti.com	Совместим	Совместим	Совместим	Совместим	Не совместим	Совместим	Совместим	See ti.com	See ti.com	Совместим	Совместим	Совместим	See ti.com	See ti.com	Совместим	Совместим	Совместим
Бессвинцовая технология (Pb Free)	Да	Да	Да	Да	Да	Да	Нет	Да

Datasheets

Корпус / Упаковка / Маркировка

	LM2576S-12	LM2576S-12/NOPB	LM2576S-3.3/NOPB	LM2576S-5.0	LM2576S-5.0/NOPB	LM2576S-ADJ/NOPB	LM2576SX-3.3/NOPB	LM2576SX-5.0/NOPB	LM2576SX-ADJ/NOPB	LM2576T-12	LM2576T-12/LB03	LM2576T-12/LF03	LM2576T-12/NOPB	LM2576T-15/LF03	LM2576T-15/NOPB	LM2576T-3.3/LB03	LM2576T-3.3/LF03	LM2576T-3.3/NOPB	LM2576T-5.0	LM2576T-5.0/LB03	LM2576T-5.0/LF02	LM2576T-5.0/LF03	LM2576T-5.0/NOPB	LM2576T-ADJ	LM2576T-ADJ/LB03	LM2576T-ADJ/LF02	LM2576T-ADJ/LF03	LM2576T-ADJ/NOPB
Pin	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5	5
Package Type	KTT	KTT	KTT	KTT	KTT	KTT	KTT	KTT	KTT	KC	NDH	NDH	KC	NDH	KC	NDH	NDH	KC	KC	NDH	NEB	NDH	KC	KC	NDH	NEB	NDH	KC
Industry STD Term	TO-263	TO-263	TO-263	TO-263	TO-263	TO-263	TO-263	TO-263	TO-263	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220	TO-220		TO-220	TO-220	TO-220	TO-220		TO-220	TO-220
JEDEC Code	R-PSFM-G	R-PSFM-G	R-PSFM-G	R-PSFM-G	R-PSFM-G	R-PSFM-G	R-PSFM-G	R-PSFM-G	R-PSFM-G	R-PSFM-T	R-MSFM-L	R-MSFM-L	R-PSFM-T	R-MSFM-L	R-PSFM-T	R-MSFM-L	R-MSFM-L	R-PSFM-T	R-PSFM-T	R-MSFM-L		R-MSFM-L	R-PSFM-T	R-PSFM-T	R-MSFM-L		R-MSFM-L	R-PSFM-T
Package QTY	45	45	45	45	45	45	500	500	500	45	45	45	45	45	45		45	45	45	45	45	45	45	45	45	45	45	45
Carrier	TUBE	TUBE	TUBE	TUBE	TUBE	TUBE	LARGE T&R	LARGE T&R	LARGE T&R	TUBE	TUBE	TUBE	TUBE	TUBE	TUBE		TUBE	TUBE	TUBE	TUBE	TUBE	TUBE	TUBE	TUBE	TUBE	TUBE	TUBE	TUBE
Width (мм)	8.42	8.42	8.42	8.42	8.42	8.42	8.42	8.42	8.42	8.51	10.16	10.16	8.51	10.16	8.51	10.16	10.16	8.51	8.51	10.16		10.16	8.51	8.51	10.16		10.16	8.51
Length (мм)	10.16	10.16	10.16	10.16	10.16	10.16	10.16	10.16	10.16	10.16	14.986	14.986	10.16	14.986	10.16	14.986	14.986	10.16	10.16	14.986		14.986	10.16	10.16	14.986		14.986	10.16
Thickness (мм)	4.58	4.58	4.58	4.58	4.58	4.58	4.58	4.58	4.58	4.58	4.572	4.572	4.58	4.572	4.58	4.572	4.572	4.58	4.58	4.572		4.572	4.58	4.58	4.572		4.572	4.58
Pitch (мм)	1.7	1.7	1.7	1.7	1.7	1.7	1.7	1.7	1.7	1.7	1.702	1.702	1.7	1.702	1.7	1.702	1.702	1.7	1.7	1.702		1.702	1.7	1.7	1.702		1.702	1.7
Max Height (мм)	4.83	4.83	4.83	4.83	4.83	4.83	4.83	4.83	4.83	4.7	4.7	4.7	4.7	4.7	4.7	4.7	4.7	4.7	4.7	4.7		4.7	4.7	4.7	4.7		4.7	4.7
Mechanical Data
Маркировка																-3.3 P+
