CD4026B, CD4033B TYPES datasheet

PDF, 875 Кб, Версия: B, Файл опубликован: 27 июн 2003

Выписка из документа

Data sheet acquired from Harris SemiconductorSCHS031B – Revised July 2003 Copyright пЈ 2003, Texas Instruments Incorporated The CD4026B-and CD4033B-series types aresupplied in 16-lead dual-in-line plastic packages(E suffix), 16-lead small-outline packages (NSRsuffix), and 16-lead thin shrink small-outlinepackages (PW and PWR suffixes). PACKAGE OPTION ADDENDUM www.ti.com 10-Jun-2014 PACKAGING INFORMATIONOrderable Device Status(1) Package Type Package Pins PackageDrawingQty Eco Plan Lead/Ball Finish MSL Peak Temp (2) (6) (3) Op Temp (В°C) Device Marking(4/5) CD4026BE ACTIVE PDIP N 16 25 Pb-Free(RoHS) CU NIPDAU N / A for Pkg Type -55 to 125 CD4026BE CD4026BEE4 ACTIVE PDIP N 16 25 Pb-Free(RoHS) CU NIPDAU N / A for Pkg Type -55 to 125 CD4026BE CD4026BNSR ACTIVE SO NS 16 2000 Green (RoHS& no Sb/Br) CU NIPDAU Level-1-260C-UNLIM -55 to 125 CD4026B CD4026BPW ACTIVE TSSOP PW 16 90 Green (RoHS& no Sb/Br) CU NIPDAU Level-1-260C-UNLIM -55 to 125 CM026B CD4026BPWE4 ACTIVE TSSOP PW 16 90 Green (RoHS& no Sb/Br) CU NIPDAU Level-1-260C-UNLIM -55 to 125 CM026B CD4026BPWR ACTIVE TSSOP PW 16 2000 Green (RoHS& no Sb/Br) CU NIPDAU Level-1-260C-UNLIM -55 to 125 CM026B CD4033BE ACTIVE PDIP N 16 25 Pb-Free(RoHS) CU NIPDAU N / A for Pkg Type -55 to 125 CD4033BE CD4033BEE4 ACTIVE PDIP N 16 25 Pb-Free(RoHS) CU NIPDAU N / A for Pkg Type -55 to 125 CD4033BE CD4033BPW ACTIVE TSSOP PW 16 90 Green (RoHS& no Sb/Br) CU NIPDAU Level-1-260C-UNLIM -55 to 125 CM033B (1) The marketing status values are defined as follows:ACTIVE: Product device recommended for new designs.LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in a new design. …
