INTEGRATED CIRCUITS
DATA SHEET
TDA1517; TDA1517P
2 x 6 W stereo power amplifier
Product specification
Supersedes data of 2002 Jan 17
2004 Feb 18

NXP Semiconductors
2 x 6 W stereo power amplifier
Product specification
TDA1517; TDA1517P
FEATURES

• Requires very few external components

• High output power

• Fixed gain

• Good ripple rejection

• Mute/standby switch

• AC and DC short-circuit safe to ground and VP

• Thermally protected

• Reverse polarity safe

• Capability to handle high energy on outputs (VP = 0 V)

• No switch-on/switch-off plop

• Electrostatic discharge protection.

GENERAL DESCRIPTION
The TDA1517 is an integrated class-B dual output
amplifier in a plastic single in-line medium power package
with fin (SIL9MPF), a plastic rectangular-bent single in-line
medium power package with fin (RBS9MPF) or a plastic
heat-dissipating dual in-line package (HDIP18). The
device is primarily developed for multi-media applications.
QUICK REFERENCE DATA
SYMBOL

VP

IORM

Iq(tot)

Isb

Isw

|ZI|

Po

SVRR

αcs

Gv

Vno(rms)

Tc

PARAMETER
supply voltage
repetitive peak output current
total quiescent current
standby current
switch-on current
input impedance
output power
supply voltage ripple rejection
channel separation
closed loop voltage gain
noise output voltage (RMS value)
crystal temperature
CONDITIONS

RL = 4 Ω; THD = 0.5%

RL = 4 Ω; THD = 10%

fi = 100 Hz to 10 kHz

MIN.
6.0
−
−
−
−
50
−
−
48
40
19
−
−
TYP.
14.4
−
40
0.1
−
−
5
6
−
−
20
50
−
MAX.
18.0
2.5
80
100
40
−
−
−
−
−
21
−
150
UNIT
V
A
mA

μA

μA

kΩ

W
W
dB
dB
dB

μV

°C

ORDERING INFORMATION
TYPE NUMBER
TDA1517/N3
TDA1517/N3/S5
TDA1517P
NAME
SIL9MPF
RBS9MPF
HDIP18
PACKAGE
DESCRIPTION
plastic single in-line medium power package with fin; 9 leads
plastic rectangular-bent single in-line medium power package with
fin; 9 leads
plastic heat-dissipating dual in-line package; 18 leads
VERSION
SOT110-1
SOT352-1
SOT398-1
2004 Feb 18
2

NXP Semiconductors
2 x 6 W stereo power amplifier
BLOCK DIAGRAM
Product specification
TDA1517; TDA1517P
handbook, full pagewidth
non-inverting
input 1
1
supply voltage
ripple rejection
output
3
mute switch Cm
60

kΩ

VA
2

kΩ

18 kΩ

VP
stand-by
switch
VA

15 kΩ

x1

15 kΩ

mute
reference
voltage

18 kΩ

4
output 1
power stage
stand-by
reference
voltage
8 mute/stand-by
switch input
mute
switch
TDA1517
non-inverting
input 2
2

kΩ

9
60

kΩ

input
reference
voltage

VA 6

mute switch Cm

signal
ground
2
7
SGND
VP
power stage
power
ground

5 (substrate)

MLC351
PGND
output 2
2004 Feb 18
Fig.1 Block diagram.
3
